The Truth Hardware (AmesburyTruth) 11577.92 is the awning window track and pivot slide assembly used with Truth Maxim Series and Encore Series awning operators. The E-Gard coated steel track (part 41015) carries two black pivot slide assemblies (part 11647) that the operator arms engage to open and close the sash. It mounts to the underside of the sash bottom rail with four screws, and is the piece to replace when the original glides wear or break and the sash no longer travels smoothly. A stainless steel version is also offered by Truth. Often called an awning track, track and slider assembly, pivot slide, or pivot glide.

Specifications

• Part number: 11577.92
• Type: Awning window track & pivot slide assembly (sill-mount application)
• Handing: Non-handed
• Material: E-Gard coated steel
• Overall length: 16" (406.4 mm)
• Mounting holes: Four, spaced 5" / 4-3/4" / 5" (127 / 120.6 / 127 mm) centre-to-centre
• Includes: Track (41015) and two black pivot slide assemblies (11647)
• Recommended screws: Four #8 x 1" flat head sheet metal screws (Truth 19240.XX)
• Compatible operators: Truth Maxim Series and Encore Series awning operators
